Three Phase Atex Certified Motors IP54 IP55 IP56 IP65 Ex Electric Motor

Brand Name : BM

Model Number : 63-800mm

Certification : CE

Place of Origin : China

MOQ : 1 PC

Price : Negotation

Payment Terms : T/T

Supply Ability : 1000 PC per month

Delivery Time : 25 days

Packaging Details : Carton/wooden case/pallet

Name : Atex Certified Motors

Protection Degree : IP54, IP55, IP56, IP65

Rated Voltage : 110V/240/ 380V /660V, Customized

Poles : 2.4.6.8.10.12

Mounting : B3 B5 B35 V1

Rated Power : 0.25kw~1600kw

Contact Now

Three Phase Explosion Proof Flameproof ATEX AC Asynchronous Induction Ex Electric Motor IP54, IP55, IP56, IP65

Electric motor frame from 56 - 355, output range from 0.17HP to 430HP

Motor mounting type B3 (IM 1001), B35 (IM 2001), B5 (IM 3001), B14 (IM 3601), B34 (IM 2101)

Optional voltage 110V, 120V, 220V, 240V, 220/380V, 230V/400V, 380V/660V, 50HZ or 60HZ

Protection type IP44, IP54, IP55 on request

1, Strengthed Base safe and srable ,stron endurance and good performance

2, High strength carbon steel shaft, the new high-strength steet shaft head is not easy to deform and durable

3, safety insulatin sleeve,anti-static,fire-proof,safe to use, electricity safty

4, Cooling hood,large hole spacing can effctively dissipate heat under the premise of ensuring safely.

Type	Asynchronous flame proof motor	Cooling Method	IC411
Phase	Three Phase	Protection Class	IP55
Voltage	380V, 660V, 380/660V/Customized	Insulation Class	F
Rated Output	0.75-315kw (1-425HP)	No. of poles	2-10 pole
Rated Frequency	50Hz/60Hz	Duty	S1

Three Phase Atex Certified Motors IP54 IP55 IP56 IP65 Ex Electric Motor

FAQ

Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
